AGCO Allis-Chalmers

ROLLER GUIDE,  Collared Hub. Main hole 1.12"ID x 1.20" long. Larger hole 2.00"ID x .34" long. 3 outside dimensions. 2.92" , 2.55" , 1.80" Overall height 1.55" Casting number 510994 Sold Individually.

HOUSING Cast metal Casting Number 511344

PIN Shaft, Stud 5/8"NF each end 3.55" overall length SHOULDER .88"OD x 1.89" long. Short threaded end tapped 3/8-24 x 1.70" deep

70511870 AGCO Allis-Chalmers SLIDE Sold Individually.

70511910 AGCO Allis-Chalmers BRACKET

ARM,  Linkage Pivot Shaft ARM

Pivot ARM PIN is .44"OD x .90" Long, Base 2.62"l x 1.00" w x oblong hole .30" x .50". Sold Individually.

70512172 AGCO Allis-Chalmers SHIM. Some have some rust on them.

LINK Arm w/ pin and oblong hole

CAP Hub Cover, Cast Metal with 4 outer holes .39"ID on 3.75" center, 3.12"ID x 1.30" deep. Overall 4.54"OD x 1.62" wide. Tapped for grease zerk/ plug.. Paint ok, some rust. Casting number 512270. ...

70512375 AGCO Allis-Chalmers Hold Down CLIP Casting Number 512375 Sold Individually.

70512378 AGCO Allis-Chalmers Hold Down CLIP Bolt Holes 3.00" Centers Casting Number 512378 Sold Individually.

STRAP 3.00" L x 1.25" W x .25" thick, Holes .68"ID and .45"ID on 1.50" centers.

70513858 AGCO Allis-Chalmers Wood SHIELD I have two of these. One has a split in the wood along part of the bottom, next to the groove.  I'll include it with the good one.  I think it still has some...

70513925 AGCO Allis-Chalmers CLUTCH Coupler

Sprocket 12T #50, 1.00"ID x 2.70"OD x 1.88" Wide, with cage roller bearing. Roller bearing not in best condition.

70514806 AGCO Allis-Chalmers PLATE

70515458 AGCO Allis-Chalmers Double GUARD

Sprocket 9T .86"ID x 4.00"OD x 1.40" Wide at hub, Has set screw. Casting number is 503628 "drive".

70516686 Compression SPRING .44"ID x .75"OD x .75"L x .14"OD Wire x 4 coils.
